FUEGO COMPACT

AEIR7S/AEIR8S/Up Light/COB/Φ205

Uplight COB Φ205

AEIR7S/AEIR8S/Up Light/COB/Φ205

FUEGO Compact adopts high quality 316 stainless steel for the face frame, aluminum die-casting and high temperature powder coating for the body. Suitable for outdoor environments, IP68 protection, IK10 anti-impact rating, anti-pressure 2000kg, high transmittance lens + patented anti-glare system. With the design of pre-buried cylinder, it is convenient for installation and maintenance. Applied to residential areas, such as parks, plazas, shopping centers as well as applied to facade lighting.

Features
Specifications

Model

Comment

Power

(W)

LEDs

(Quantity)

Max Lumens

(lm)

Control   Systems

Beam

CCT

Finish

AEIR7S

High Lumens

F  Frame

21 21(Max)

COB

2030

EL   ON-OFF
220V AC Power Supply

2   22°

4   45°

5   53°

6   63°

27  2700K

30  3000K

40  4000K

SS   Stainless Steel

Model

Comment

Power

(W)

LEDs

(Quantity)

Max Lumens

(lm)

Control   Systems

Beam

CCT

Finish

AEIR8S

Super Comfort

F  Frame

21 21(Max)

COB

1192

EL   ON-OFF
220V AC Power Supply

2   21°

4   40°

5   50°

6   60°

27  2700K

30  3000K

40  4000K

SS   Stainless Steel

Example: AEIR8SF-21EL227SS
